Thermaltake
Core P6 TG
Core P6 TG
SKU:CA-1V2-00M6WN-00
In stock
Couldn't load pickup availability
The Thermaltake Core P6 Tempered Glass Midi Tower Chassis is an innovative and convertible case that can be used as both a closed and open case. Featuring a fully modular design, rotatable PCI-E slots, a power supply shroud, and an additional GPU bracket, this case offers a high degree of flexibility for your individual needs.
The Core P6 TG supports a variety of cooling options and accommodates up to thirteen 120mm fans and radiators up to 360mm in size on the front and top. It's ideal for powerful builds and offers excellent expansion options. The maximum height for CPU coolers is 180mm, while graphics cards up to 300mm in length and power supplies up to 200mm are supported. Removable dust filters ensure easy cleaning and maintenance.
| series | Core |
|---|---|
| TYPE | Midi Tower |
| DIMENSIONS (Height x Width x Depth) | 565 x 255 x 530mm (22.2 x 10 x 20.9 inches) |
| NET WEIGHT | 17.84 kg / 39.33 lbs. |
| SIDE PANELS | 4mm tempered glass x 3 |
| MATERIAL | SPCC |
| DRIVES | 4 x 3.5” or 8 x 2.5” |
| EXTENSION | 7 (Rotatable Patented Design) |
| Motherboards | 6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX), 12” x 10.5” (CEB) |
| I/O PORT | USB 3.2 (Gen 2) Type-C x 1, USB 3.0 x 2, USB 2.0 x 2, HD Audio x 1 |
| POWER SUPPLY | Standard PS2 PSU (optional) |
| FAN SUPPORT | Front: 3 x 120mm, 2 x 120mm, 1 x 120mm 2 x 140mm, 1 x 140mm Top: 3 x 120mm, 2 x 120mm, 1 x 120mm 2 x 140mm, 1 x 140mm Rear: 1 x 120mm Right (M/B Side): 3 x 120mm, 2 x 120mm, 1 x 120mm 2 x 140mm, 1 x 140mm Bottom: 3 x 120mm, 2 x 120mm or 1 x 120mm 2 x 140mm, 1 x 140mm |
| RADIATOR SUPPORT | Front: 1 x 360mm, 1 x 240mm, 1 x 120mm 1 x 280mm, 1 x 140mm Top: 1 x 360mm, 1 x 240mm, 1 x 120mm 1 x 280mm, 1 x 140mm Rear: 1 x 120mm Right (M/B Side): 1 x 360mm, 1 x 240mm, 1 x 120mm 1 x 280mm, 1 x 140mm Bottom: 1 x 240mm, 1 x 120mm |
| POSSIBILITIES | CPU cooler height limitation: 180mm VGA length limitation: 300mm (With Reservoir) 400mm (without reservoir) 430mm (With Radiator) 458mm (without radiator) PSU length limitation: 200mm |
Whether you're a gaming enthusiast or a PC builder, the Core P6 TG gives you the flexibility and features you need to customize your system.
