Compact power, limitless performance

The Toughpower SFX Platinum series is designed to support next-gen hardware and meets the latest Intel SFX 12V 4.1 and ATX 12V 3.1 standards. With its native modular PCIe 12V-2x6 (12+4pin) interface, it efficiently powers PCIe 12+4pin graphics cards. This series not only achieves 80 PLUS Platinum efficiency but also guarantees stability, durability, and reliability.

Regardless of the case size, we have everything for you

The dimensions of the Toughpower SFX Platinum are 125mm(W) x 63.5mm(H) x 103.8mm(D).
An SFX-to-ATX adapter bracket is included as an accessory, giving users more options when choosing the ideal case for their build.

Full compatibility with ATX 3.1 standards

The Toughpower SFX Platinum series is fully compatible with ATX 3.1 specifications, supports up to 200% power surge, achieves 60% efficiency at low load, and meets the required timing standards for Power Supplies.

PCIe Gen 5.1 Ready

The Toughpower SFX Platinum series is equipped with a PCIe 12V-2x6 connector that provides strong and stable power, allowing the Power Supply to natively support next-generation GPUs.

The wattage indicated on the 12+4-pin PCIe cable connector corresponds to the recommended wattage (see Intel design guideline). The included PCIe Gen 5.1 (12+4pin) cable connector of the Toughpower SFX Platinum 750W can deliver up to 300W for PCIe 12+4pin graphics cards.

1. Note:
2. The recommended wattage is an estimate of the system's power demand. Actual power consumption may vary depending on specific components, usage, and many other factors.
3. Please observe the recommended power requirements from GPU manufacturers before using the PCIe 12+4pin cable.

Suitable for the latest graphics cards

The Toughpower SFX Platinum series is designed to power NVIDIA and AMD graphics cards. It supports 8-pin slots for AMD graphics cards and some RTX 40 series cards, and also features a 12V-2x6 connector for RTX 40 series cards with a PCIe 12+4-pin connector.

Be Smart, Stay Quiet

Equipped with a 90mm fluid dynamic bearing fan for excellent airflow. The built-in Smart Zero Fan feature ensures the fan is quiet up to a 30% load, reducing unwanted noise.

The 80 PLUS Platinum certification means that the Toughpower SFX Platinum series converts power efficiently and saves energy with its high efficiency of up to 92%, resulting in lower power loss and heat generation inside the Power Supply.

<30mV design with low residual ripple

First-class build quality with low residual ripple. All ripples are below 30mV on +12V, +5V, or +3.3V from 0% to 100% load to ensure stable operation and keep your power-critical components running reliably longer.

Extremely strict voltage regulation ＜±2%

Voltage regulation is stricter than Intel's standard +5%, -7% for the main rails and ±10% for -12V, set to no more than ±2% for the main rail, providing smooth, clean power through exceptional voltage stability.

17ms and more hold-up time

In the event of a power interruption, your computer can shut down or restart. We ensure that the SFX Platinum series delivers at least 17 ms at 80% load without the system restarting or resetting.

More stable than ever

100% high-quality Japanese 105°C/221°F electrolytic capacitors ensure a long lifespan and provide the highest stability while maintaining reliability.

High current single +12V
Rail & High-Class technologies

The powerful single +12V rail can correctly deliver the power needed for the best compatibility. The use of LLC and DC/DC circuits ensures very stable operation and improved voltage regulation.

Fully modular low-profile cables

Offers the user the choice of cable and supplies the system with advantageous voltage. Low-profile cables facilitate cable management, reduce clutter, and improve airflow inside the case.

Integrated industrial-grade protection

Equipped with industrial-grade protection features to safeguard the hardware: OCP (Over Current Protection), OVP (Over Voltage Protection), UVP (Under Voltage Protection), OPP (Over Power Protection), SCP (Short Circuit Protection), OTP (Over Temperature Protection).

Intel C6/C7 States Ready

The Toughpower SFX Platinum series has been optimized for use with all generations of Intel processors to achieve maximum energy savings.

7 years warranty

 Trusting in the reliability of our Toughpower SFX Platinum series, we offer a 7-year warranty, firmly standing behind the exceptional quality and lasting performance of our products.

   Specification
